TERMINAL BLOCK 2x 2.5mm², with Fuse Holder
Code CKKV2S- Weight 5.00g
E-shop price: 0,65 €
| Amount: | 5+ | 10+ | 25+ |
| Price: | 0,59 | 0,53 | 0,53 |
Minimum order: 1 Repeatability : 1
Amount
Cleanup sale, availible quantity: 16pcs.
Cleanup sale, availible quantity: 16pcs.
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item is not available (0) | |
| Shop in Vilnius | Item available (5) | |
| Shop in Kaunas | Item available (11) | |
Item description
Mechanical mounting: for cable, for panel mounting, mounting holes
Rated voltage: 250V
Current rating: 6.3A
Operating temperature: -40...105°C
Flammability rating: UL94V-0
Colour: grey
Body material: polyamide
Contact material: brass
Contact plating: tinned
Mounting hole diameter: 2.2...3.2mm
Wire size: 22AWG...14AWG
Wire cross section: 0.5...2.5mm2
Connector variant: fuse x1
Fuse size: 5x20mm
Conform to the norm: CE, UL, VDE
