7631 Safety tester; 1Ω÷12GΩ; Utest: 10÷5000VAC,10÷6000VDC; True RMS

• Operating temperature — 5…40
• Supply voltage AC — 90…264
• Supply voltage DC — 90…264
• Insulation resistance measuring ranges — 1…12000000000
• Test voltage — 10…1000
• Testēšanas frekvence — 50…60
• —
• Standard equipment — mains cable
• Standard equipment — control pedal F760001
• Interface — Remote
• Interface — USB Host
• Kind of display used — LCD TFT 4,3"
• Interface — USB device
• —
• —
• True effective value measurement — True RMS
• —
• —
• Interface — EXT I/O
• Measuring instrument features — 30 sets setting memory
• Measuring instrument features — Key-Lock function
• Kind of meter — Hi-Pot
• —
• Measuring instrument features — True RMS measurement
• Measuring instrument features — manual and automated tests
• —
• —
• Display resolution — 480x272
• Dimensions — 435x145x500mm
• Interface — RS232
• —
• —
• —
• —
• Standard equipment — test lead x2
• Measuring instrument features — ARC (Arcing detection)- Transient detection
• —
• Type of meter — safety tester
• Measuring instrument features — insulation resistance test 100-500V, 1-1000MΩ (±5%); 500-1000V, 2-12000MΩ (±5%)
• Measuring instrument features — safety interlock function
• —
• —
• Measuring instrument features — remote control
