38.81.7.024.7048 Relay: interface; Ucoil: 24VDC; SPST-NO; 80A; 2A/240VAC; 6A/24VDC

• Operating temperature — -20°C…55°C
• Rated coil voltage DC — 24V DC
• —
• Relay variant — Relay set
• Switched voltage — 1.5...48V DC
• Kit contents — 93.01.7.024
• Mounting — for DIN rail mounting
• DC contacts rating @R — 6A / 24V DC
• Type of relay — interface
• —
• Manufacturer — FINDER
• AC contacts rating @R — 2A / 240V AC
• IP rating — IP20
• —
• DC contacts rating @R — 0.1A / 48V DC
• —
• —
• —
• Body dimensions — 87.9x6.2x75.6mm
• —
• Leads — screw terminals
• —
• Contacts configuration — SPST-NO
• —
• Kit contents — 34.81.7.024.7048
• Rated coil voltage — 24V DC
