AMP-330-EUR Meter: multifunction; digital,AC/DC pincers type; Øcable: 51mm

• Temperature measuring range — -40°C…400°C
• Capacitance measuring range — 0F…2.5mF
• DC current measuring range — 0A…1kA
• AC current measuring range — 0A…1kA
• AC voltage measuring range — 0V AC…1kV AC
• Resistance measuring range — 0Ω…60kΩ
• DC voltage measuring range — 1V DC…1kV DC
• Max. diameter of measured cable — 51mm
• —
• —
• —
• —
• Standard equipment — case
• Measurement — temperature
• Frequency measuring range — 5...999.9Hz
• —
• —
• —
• Measurement — capacitance
• Measurement — frequency
• —
• Measurement — inrush current
• Measurement — DC current
• Standard equipment — test leads
• Measurement — AC voltage
• —
• Manufacturer — BEHA-AMPROBE
• True effective value measurement — True RMS
• Measuring instrument features — MIN/MAX/MEDIUM function
• Kind of display used — LCD
• Standard equipment — user's manual
• Measuring instrument features — PEAK HOLD function
• Measurement — resistance
• —
• —
• —
• —
• —
• —
• Measuring instrument features — HOLD function
• Measuring instrument features — contactless voltage detector
• —
• —
• Conform to the norm — CAT IV 600V
• —
• Measuring instrument features — automatic power-off
• Conform to the norm — EN 61010
• —
• Standard equipment — drop-like K-type probe
• —
• —
• Kind of meter — pincers type
• Measuring instrument features — low-pass filter for measuring drive parameters
• —
• Kind of meter — digital
• —
• Type of meter — multifunction
• Body dimensions — 258x94x44mm
• Illumination — yes
• Continuity test — acoustic indication
• —
• Display parameters — (6000)
• Measurement — AC current
• Conform to the norm — CAT III 1000V
• Measurement — DC voltage
