BM 93CS3 Connector: terminal block; 400V; with wire protector; natural

• Rated voltage — 400V
• Operating temperature — 125°C
• Length — 16.6mm
• Number of terminals — 6
• —
• —
• Manufacturer — BM GROUP
• Conform to the norm — CSA
• —
• Mechanical mounting — for cable
• —
• —
• Mechanical mounting — mounting holes
• Connector variant — with wire protector
• —
• —
• Mechanical mounting — for panel mounting
• Body material — polyamide 66
• —
• Conform to the norm — CE
• Contact plating — nickel plated
• Flammability Rating — UL94V-2
• Conform to the norm — EN
• Contact material — brass
• Electrical mounting — screw terminal
• Colour — natural
• —
• —
• —
• —
• Type of connector — terminal block
• Conform to the norm — UL
