CONNECTOR female XT30, 15A 500VDC

Code CJ601L
  • Weight 4.00g

E-shop price: 0,90 €

Amount: 5+ 10+
Price: 0,85 0,84
Minimum order: 1 Repeatability : 1

Item location:
Central warehouse in Kaunas Item available (4)
Shop in Vilnius Item available (5)
Shop in Kaunas Item available (6)

Item description

Connector: plug
Type of connector: DC supply
Connector series: XT30
Kind of connector: female
Number of pins: 2
Mechanical mounting: for cable
Electrical mounting: soldered
Contact plating: gold flash
Colour: yellow
Current rating: 15A
Flammability rating: UL94V-0
Operating temperature: -20...120°C
Rated voltage: 500V
Spatial orientation: straight
Contact material: brass
Mechanical durability: 1000cycles
Body material: polyamide
Wire size: 18AWG
