Plug RCA NEUTRIK Group, Rean NYSS373-5, green
Code CKI149Z- ID code NYS373-5
- Weight 0.00g
E-shop price: 2,40 €
| Amount: | 4+ | 8+ |
| Price: | 2,23 | 2,14 |
| 2,46 | 2,35 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item available (5) | |
| Shop in Vilnius | Item available (5) | |
| Shop in Kaunas | Item available (4) | |
Description
Plug with gold plated contacts, black chromium shell, chuck type strain relief, color marking ring
Electrical
Contact Resistance: ≤10 mΩ
Insulation Resistance: >2000 MΩ(Initial)
Rated Voltage: 0.5 VAC
Mechanical
Insertion and Withdrawal Force: 5-20N
Lifetime: >5000 Mating Cycles
Material
Pin: Brass / Gold
Housing: Copper / Gold
Boot: PVC
Ground Contact: H62
Chuck: PA6
Color dividing ring: Rubber
Elastic clamp: ABS
Ground Contact: Gold
