EX655 Meter: multifunction; digital,AC/DC pincers type; Øcable: 30mm

• Temperature measuring range — -40°C…1k°C
• Capacitance measuring range — 60mF
• AC current measuring range — 600A
• DC current measuring range — 600A
• DC voltage measuring range — 1kV DC
• AC voltage measuring range — 750V AC
• Resistance measuring range — 60MΩ
• Max. diameter of measured cable — 30mm
• —
• —
• Measuring instrument features — non-contact voltage detector
• Standard equipment — temperature probe
• —
• Measurement — temperature
• —
• —
• —
• Measurement — capacitance
• —
• —
• Measurement — frequency
• Measurement — inrush current
• Conform to the norm — CAT III 600V
• Measurement — DC current
• Standard equipment — test leads
• —
• —
• —
• Measurement — AC voltage
• —
• —
• —
• —
• —
• —
• Kind of display used — LCD
• —
• Measurement — resistance
• —
• —
• —
• —
• Measuring instrument features — auto and manual ranging
• Continuity test — <30Ω
• Conform to the norm — CAT II 1000V
• —
• —
• Measuring instrument features — HOLD function
• —
• —
• —
• —
• —
• Measuring instrument features — automatic power-off
• Conform to the norm — EN 61010
• Kind of meter — pincers type
• Manufacturer — EXTECH
• Measuring instrument features — low-pass filter for measuring drive parameters
• —
• True effective value measurement — True RMS AC
• —
• Dimensions — 288x77x41mm
• Kind of meter — digital
• Type of meter — multifunction
• —
• Illumination — yes
• Continuity test — acoustic indication
• —
• —
• —
• Display parameters — (6000)
• —
• Frequency measuring range — 10...1MHz
• Measurement — AC current
• —
• —
• —
• —
• —
• Measurement — DC voltage
• —
• —
• —
• —
