FLUKE-1577 Digital multimeter; LCD; (6000); VDC: 0.1÷600mV,6V,60V,600V,1kV

• DC current measuring range — 400mA
• AC current measuring range — 400mA
• AC voltage measuring range — 1kV AC
• DC voltage measuring range — 1kV DC
• Resistance measuring range — 50MΩ
• Test voltage — 1000
• Insulation resistance measuring ranges — 500000000
• —
• —
• Measuring instrument features — automatic discharge of capacitance charge function
• —
• —
• Standard equipment — harda case FLK-C101
• —
• Standard equipment — test leads FLK-TL224 SureGrip
• —
• Measurement — DC current
• Measuring instrument features — indicates incorrect connection of test leads
• —
• Measurement — AC voltage
• —
• —
• —
• Measuring instrument features — automatic stop of insulation test when voltage higher than 30V is detected
• Kind of display used — LCD
• —
• —
• Measurement — resistance
• —
• Measuring instrument features — auto and manual ranging
• Continuity test — <25Ω
• —
• —
• Measurement — insulation resistance
• —
• —
• Measuring instrument features — HOLD function
• Type of meter — digital multimeter
• —
• Manufacturer — FLUKE
• —
• Dimensions (W x H x D) — 100x203x50mm
• Conform to the norm — CAT IV 600V
• Measuring instrument features — automatic power-off
• —
• Conform to the norm — EN 61010
• Standard equipment — crocodile clips FLK-AC285
• —
• —
• —
• True effective value measurement — True RMS AC
• Standard equipment — test probe FLK-TP165X
• —
• —
• Measuring instrument features — insulation resistance test
• —
• Illumination — yes
• Continuity test — acoustic indication
• —
• —
• —
• Display parameters — (6000)
• Measurement — AC current
• Conform to the norm — CAT III 1000V
• —
• —
• Measurement — DC voltage
• —
• —
• —
• —
