GDF1R10MV2 Automation module: timer; Range: 0,05s÷9999h; SPDT; 24÷240VAC

• Number of pins — 11
• Supply voltage AC — 24V AC…240V AC
• Operating temperature — -10°C…60°C
• Supply voltage DC — 24V DC…240V DC
• Number of operation modes — 10
• Counter operation modes — ON and OFF delay
• Counter operation modes — cyclical operation with two independent times T1 and T2, pause first
• Kind of output — SPDT
• —
• Electrical connection — round socket
• Counter operation modes — cyclic operation with delayed switching off
• —
• Mounting — on panel
• —
• —
• Output 1 electrical parameters — 250V AC / 10A
• Mounting hole diameter — 45x45mm
• Counter operation modes — delayed switching off
• The additional control inputs — START
• Manufacturer — CROUZET
• Type of module — timer
• Counter operation modes — symmetrical cyclical operation swithing on first with two independent times T1 and T2
• Mounting — socket
• —
• —
• —
• Type of automation module — timer
• Counter operation modes — ON for the set interval
• —
• Kind of display used — LED
• —
• Counter operation modes — symmetrical cyclical operation pause first with two independent times T1 and T2
• The additional control inputs — RESET
• —
• Counter operation modes — cyclical operation with two independent times T1 and T2, pulse first
• Counter operation modes — delayed switching on
• —
• —
• Counting range — 0,05s...9999h
• Counter operation modes — with the control contact S
