FILM CAPACITOR 3.3uF 1000VDC ±3% Ø41x57mm Mundorf Supreme Silver / Oil

The MCap® SUPREME Silver.Oil is an
oil impregnated metallised polyprophylene
dielectric capacitor. As the name indicates,
high-purity silver is used for the capacitor
coating, and the winding is impregnated with
a special oil developed in an exhaustive
series of experiments and listening tests.
Both these features contribute to an even
fuller and smoother tonal richness and diversity.
Our state-of-the-art metallised polyprophylene
foils make it possible to maintain
extremely low production tolerances that
cannot be achieved with traditional oil/paper
capacitor designs. This is also the fi rst time
that the benefi ts of oil-impregnated capacitor
design have been successfully combined
with the well-known long-term stability of
polypropylene foil and internal series wiring
for induction-free SUPREME performance.
(see also page 9)
Its lively reproduction of music impresses
in particular with its subtly dynamic speed,
precision and marked fi ne detail.
Technical specifi cations:
Dielectric: Polypropylene
Dielectric strengh: 1 000 VDC
Loss factor: tan ∂ = 0.0002 @1 kHz
