Thermal relay - Thermal protection 10A 70°C disconnect / 55°C connect
Code RLTL07L- Weight 4.38g
E-shop price: 1,95 €
| Amount: | 3+ | 5+ |
| Price: | 1,68 | 0,71 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item available (1) | |
| Shop in Vilnius | Item available (2) | |
| Shop in Kaunas | Item available (1) | |
Item description
A bimetallic thermostat is designed to switch an electrical circuit at a given temperature. The thermostat contacts are disconnected when the working temperature is reached. When the temperature drops, the contacts are reconnected.
Voltage limit : 250 VAC
Permissible current : up to 10 A
Terminals : 6,3 mm
Contact disconnects : at 70 ± 5 °C
Contact reconnects : at 55 ± 5 °C
Contact : NC (normally connected)
