1-1393203-1 Relay: electromagnetic; SPDT; Ucoil: 24VDC; 5A; 7A/250VAC; 7A/24VDC

• Contacts pitch — 5.08mm
• Operating temperature — -25°C…70°C
• Rated coil voltage DC — 24V DC
• Contact current max. — 5A
• Switching capacity — 1.75kW
• Operate time — 5ms
• Coil power consumption — 450mW
• Coil resistance — 1.28kΩ
• AC contacts rating @R — 7A / 250V AC
• —
• DC contacts rating @R — 7A / 24V DC
• Relay variant — miniature
• Contact material — AgNi 90/10
• Terminal pitch — 5.08mm
• —
• Type of relay — electromagnetic
• —
• —
• Mounting — PCB
• —
• —
• Manufacturer — TE Connectivity
• Switched voltage — max. 60V DC
• Contacts configuration — SPDT
• —
• —
• Switched voltage — max. 400V AC
• —
• Rated coil voltage — 24V DC
• Body dimensions — 21.2x16.2x14.9mm
