BK394B Digital multimeter; USB; LCD; 5 digits (50000); 10x/s; -10÷50°C

• Operating temperature — -10…50
• DC current measuring range — 1A
• DC voltage measuring range — 1000
• Maiņstrāvas sprieguma mērīšanas diapazons — 1000
• AC current measuring range — 1A
• Resistance measuring range — 50000000
• —
• Display parameters — 5 digits (50000)
• —
• Dimensions — 95x207x52mm
• —
• Standard equipment — magnetic catch
• —
• —
• —
• —
• Measurement — frequency
• Measurement — 4-20mA current loop
• —
• Measurement — DC current
• Standard equipment — test leads
• —
• —
• Measurement — 0-20mA current loop
• Measurement — AC voltage
• —
• —
• Measuring instrument features — 24V loop supply voltage
• Measuring instrument features — HART communication
• —
• Continuity test — <500Ω
• —
• Kind of display used — LCD
• Measuring instrument features — low battery indicator
• —
• Measuring instrument features — low-pass filter
• Measurement — resistance
• —
• —
• —
• Frequency measuring range — 100kHz
• Manufacturer — B&K PRECISION
• —
• Standard equipment — USB cable
• —
• —
• Frequency measuring range — 500Hz
• Type of meter — digital multimeter
• Conform to the norm — CAT IV 600V
• Measuring instrument features — automatic power-off
• Conform to the norm — EN 61010
• —
• Interface — USB
• Frequency measuring range — 5kHz
• True effective value measurement — True RMS AC
• —
• —
• —
• Frequency measuring range — 50kHz
• —
• Sampling — 10x/s
• Illumination — yes
• Continuity test — acoustic indication
• —
• Measurement — AC current
• —
• Conform to the norm — CAT III 1000V
• Measurement — DC voltage
• True effective value measurement — True RMS AC+DC
• —
• —
• Measuring instrument features — simultaneous readout in mA and % of range
• —
• —
• —
