UNIVERSAL POWER TEST DEVICE DL24/P, 2.4", 150W

DL24/P Color 2.4" DC USB tester electronic load lithium battery capacity monitor discharge charge power meter supply checker APP
- Compatible with discharging and aging testing of various USB chargers, various power bank mobile power supplies, various battery and battery capacities, various power adapters and other power supply equipment voltage, current, power, capacity, power,temperature, discharge resistance, time-limited discharge settings , Stop voltage setting and other parameters and operations
- Four major online APPs (Android, Apple, PC computer Bluetooth wireless and data wired connection APP), compatible with four major discharge modes (full coverage of constant current, constant power, constant resistance, and constant voltage)Compatible with both Bluetooth wireless/wired connection modes
- The advantage of the four-wire system（Support 2-wire system）, the voltage measurement is not affected by the voltage drop of the wire, and the voltage is more accurate when used to detect the battery;The 2.4-inch high-definition wide color screen interface design enjoys a different color visual experience.
- Discharge can more accurately stop the discharge and protect the battery. The internal use of high-power large discharge tube discharge test, summarizes hundreds of large-scale instrumentation circuit principle and evolutionary extraction, all major advantages are integrated; discharge aging, a screen full of multiple parameters , The test is convenient and fast, and the function is strong! The play test is diverse!
- Easily test various data such as voltage/current/capacity of various lithium batteries/batteries, continuous load discharge aging test, adopts intelligent temperature control fan design, built-in large discharge tube, greater power More reliable, test the overall capacity of the battery, use time, aging performance, etc

Product Parameter
Test voltage：2~200V
Working current：0.2~20A
DL24 Discharge power: voltage * current < 150 W
(The actual running current is limited by the maximum power, please adjust the current according to the law of energy conservation)
Overload protection(when >185W)
Overcurrent protection(when >21A )
High temperature protection(when >100°C)
The built-in over-current, over-temperature, over-power safety protection functions
