Digital PID Temperature Controller 400°C ATIT17.jpg

Digital PID Temperature Controller 400°C

Code ATIT17
  • Weight 120.00g

E-shop price: 19,90

Amount: 3+ 5+
Price: 17,51 13,42
Minimum order: 1 Repeatability : 1

Amount
Item location:
Central warehouse in Kaunas Item is not available (0)
Shop in Vilnius Item available (1)
Shop in Kaunas Item available (2)

Item description

· Display: Dual display for Celsius (°C)

· Range: 0-400°C (Only when with the factory K type thermocouple)

· Thermocouple: Type K

· Main Output: SSR

· PID cooling/heating control

· 1 RELAY alarm: Normal open, capacity 250V/3A AC or 30V/3A DC

· 7 different Dual Output combinations with: high / low / high deviation / low deviation /interval / out of interval / breakage alarm

· Accuracy: 0.5%

· Input: Type K

· Dimension: DIN: 1/16 (48mm x 48mm x 108mm/1.89"x1.89"x4.25")

· Individually programmable PID control parameters.

· P, I, d, controlling period, digital filter coefficient, and more

· Relay control ready to connect

· Compact design:

· DIN 1/8 great form-factor to be included/build-in to your product.

· Input: Type K

· Control output: SSR

· Alarm output: 1 line output, 7 kinds of alarm mode: high/low/high deviation/low deviation/interval/out of interval/breakage alarm.

Specification
