CONNECTOR 5pin Male 2mm, 1A 100V, soldered
Code CJK6505- Weight 0.40g
E-shop price: 0,1000 €
| Amount: | 100+ | 200+ | 300+ |
| Price: | 0,0850 | 0,0379 | 0,0337 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item available (260) | |
| Shop in Vilnius | Item available (19) | |
| Shop in Kaunas | Item available (27) | |
Item description
Maximum operating voltage 100 V
Maximum current 1 A
Housing material polyamide
Contact coating tin-plated
Width 12,1 mm
Maximum contact resistance: 20 mOM
Operating temperature -25...85°C
Flammability class UL94V-0
