SWITCH ON-OFF 3-6V DC, 5A 12V DC, 5A 250V AC, ø19mm, IP67, with yellow LED indication
Code CPR01918AG- Weight 18.00g
E-shop price: 3,90 €
| Amount: | 4+ | 8+ |
| Price: | 3,51 | 3,38 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item available (20) | |
| Shop in Vilnius | Item available (5) | |
| Shop in Kaunas | Item available (5) | |
Description
Type: SPDT 1NO1NC Fixed Switch with Illuminated Ring
Housing Material: Stainless Steel/Nickel Plated Brass/Aluminum Alloy
Technical data:
* Rated load: 5A 12V DC, 5A 250V AC
* Contact resistance: ≤50 mΩ
* Insulation resistance: ≥1,000 mΩ at 500V DC
* Dielectric strength: 2,000V AC
* Mechanical life: ≥500,000 cycles
* Electrical life: ≥50,000 cycles
* Protection class: IP65 (protection against dust and water)
* Operating force: 3.5±1 N
