VANDAL RESISTANT SWITCH ON 2A 36V, stainless steel, 19mm
Code CPR01919S- Manufacturer ONPOW
- ID code GQ19F-10/N
- Weight 22.00g
E-shop price:
4,60 €
5,95 €
| Amount: | 4+ | 8+ |
| Price: | 4,19 | 3,95 |
| 5,30 | 5,00 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item available (4) | |
| Shop in Vilnius | Item available (5) | |
| Shop in Kaunas | Item available (3) | |
Description
Contacts configuration: SPST-NO
IP rating: IP65
Operating temperature: -20...55°C
Electrical life: 200000 cycles
Max. contact resistance: 50mΩ
Operating Force: 4N
Mechanical durability: 1000000 cycles
Button shape: flat
Mounting hole diameter: Ø19mm
Body material: stainless steel
Test voltage: 2kV
Contact material: silver alloy
