FULLRANGE SPEAKER BF37 4 Om
Code GAVSPBF37- Manufacturer VISATON
- ID code 2260
- Weight 60.00g
E-shop price: 14,90 €
| Amount: | 2+ | 4+ |
| Price: | 14,15 | 13,71 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item is not available (0) | |
| Shop in Vilnius | Item is not available (0) | |
| Shop in Kaunas | Item available (2) | |
Description
3.7 cm (1.5") fullrange speaker with a wide and balanced frequency response and very good low range reproduction. With powerful Neodymium driver and high membrane excursion limit, optimized for small vented enclosures/enclosures with passive radiator. Suitable for applications where slim construction and good music and speech reproduction are requested.
Flat TVs
Info terminals
other compact devices speech and music reproduction
Technical Data
- Rated power 5 W
- Excursion limit +/-3.4 mm
- Resonance frequency fs 155 Hz
- Net weight 33.1 g
- D.C. resistance Rdc 3.8 Ohm
- Mechanical Q factor Qms 5.11
- Electrical Q factor Qes 0.86
- Total Q factor Qts 0.74
- Equivalent volume Vas 0.06 l
- Effective piston area Sd 6.2 cm²
- Dynamically moved mass Mms 1.0 g
- Force factor Bxl 1.99 Tm
- Inductance of the voice coil L 0.17 mH
- Connections Soldering ears
