FULLRANGE SPEAKER FR10 4Ω VISATON
Code GAVSPFR10- Manufacturer VISATON
- ID code 2020
- Weight 404.00g
E-shop price: 17,90 €
| Amount: | 3+ | 5+ |
| Price: | 17,00 | 16,47 |
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item available (2) | |
| Shop in Vilnius | Item available (2) | |
| Shop in Kaunas | Item available (2) | |
Item description
10 cm (4“) fullrange speaker with good bass reproduction, balanced frequency response and high efficiency. Especially suitable as built-in speaker for music reproduction and as driver for 100 V network column speakers.
Technical Data:
Rated power 30 W
Opening angle (-6 dB) 113°/4000 Hz
Excursion limit +/−4 mm
Resonance frequency fs 88 Hz
Magnetic induction 0,95 T
Magnetic flux 180 µWb
Height of front pole-plate 3 mm
Voice coil diameter 20 mm
Height of winding 6 mm
D.C. resistance Rdc 7,2 Ohm
Mechanical Q factor Qms 2,29
Electrical Q factor Qes 0,95
Total Q factor Qts 0,67
Equivalent volume Vas 2,3 l
Effective piston area Sd 50 cm²
Dynamically moved mass Mms 5,7 g
Force factor Bxl 4,6 T m
Inductance of the voice coil L 0,2 mH
Connections 5,2 x 0,5 mm (+)
2,8 x 0,5 mm (−)
Temperature range −25 ... 70 °C
