GDS2R10MV2 Timer; Range: 0,05s÷9999h; SPDT x2; 24÷240VAC; 24÷240VDC; TMR48D

• Number of pins — 11
• Operating temperature — -10°C…60°C
• Supply voltage AC — 24V AC…240V AC
• Supply voltage DC — 24V DC…240V DC
• Number of operation modes — 16
• Counter operation modes — cumulative cyclic work T1 and T2
• Counter operation modes — ON and OFF delay
• —
• Electrical connection — round socket
• Counter operation modes — cyclic operation with delayed switching off
• —
• Counter operation modes — symmetrical cyclical operation pulse first
• Mounting — on panel
• —
• —
• Output 1 electrical parameters — 250V AC / 10A
• Counter operation modes — symmetrical cyclical operation pause first
• Mounting hole diameter — 45x45mm
• Counter operation modes — delayed switching on, sum of times T1, T2 and T3
• —
• Counter operation modes — delayed switching off
• The additional control inputs — START
• Counter operation modes — switching on the set time after pulse of contact S
• Manufacturer — CROUZET
• Type of module — timer
• Counter operation modes — symmetrical cyclical operation swithing on first with two independent times T1 and T2
• Mounting — socket
• —
• —
• —
• Type of automation module — timer
• Counter operation modes — ON for the set interval
• —
• Kind of display used — LED
• —
• Counter operation modes — symmetrical cyclical operation pause first with two independent times T1 and T2
• The additional control inputs — RESET
• —
• Counter operation modes — measuring a single duty cycle and breaks
• Counter operation modes — cyclical operation with two independently preset times
• Counter operation modes — cumulative
• Counter operation modes — delayed switching on
• —
• —
• Counting range — 0,05s...9999h
• —
• Kind of output — SPDT x2
• Counter operation modes — with the control contact S
