GEN-8-600-3P400 Laboratory power supply: programmable; single-channel; 0÷8VDC

• Maximum power — 4.8kW
• Output voltage — 0V…8V
• Output current — 0A…600A
• Operating temperature — 0°C…50°C
• Software — LabVIEW
• —
• —
• Measuring instrument features — front panel lockout
• Mounting — rack 19"
• Interface — RS485
• Measuring instrument features — master/slave mode for parallel operation
• —
• —
• Kind of power supply — single-channel
• —
• —
• Measuring instrument features — automatic CV/CC crossover operation
• Number of channels — 1
• Kind of input connector — terminal block
• Measuring instrument features — Auto-Re-Start and Safe-Start function
• —
• —
• Interface — RS232
• Kind of display used — LED x2
• Measuring instrument features — LabWindows driver
• —
• Display parameters — 4-digit
• Measuring instrument features — parallel mode operation
• —
• —
• Dimensions (W x H x D) — 423x88x442.5mm
• —
• Voltage between phases (for three phase system) — 3 x 342...460V AC
• Measuring instrument features — last setting memory
• Manufacturer — TDK-LAMBDA
