FAN 12VDC 60x60x10mm, 24m3/h, 25dBA IVT2061.jpg

FAN 12VDC 60x60x10mm, 24m3/h, 25dBA

Code IVT2061
  • Manufacturer SUNON
  • ID code MF60101V21000UA99
  • Weight 31.00g

E-shop price: 6,50

Amount: 3+ 4+
Price: 6,18 5,92
Minimum order: 1 Repeatability : 1

Amount
Item location:
Central warehouse in Kaunas Item available (2)
Shop in Vilnius Item available (2)
Shop in Kaunas Item available (4)

Description

🌬️ Sunon MF60101V2-1000U-A99 – DC Axial Fan

Manufacturer: SUNON
Model: MF60101V2-1000U-A99
Series: MagLev® MF

🔧 Technical Specifications

  • Voltage: 12 V DC (operating range: 4.5–13.8 V)
  • Current: 75 mA
  • Power Consumption: 0.9 W
  • Speed: 3500 RPM
  • Airflow: 24.17 m³/h (14.3 CFM)
  • Static Pressure: 2.54 mm H₂O
  • Noise Level: 25 dBA
  • Bearing Type: Vapo-Bearing™
  • Dimensions: 60 × 60 × 10 mm
  • Weight: 23 g
  • Lead Length: 290 mm (2 wires, 26 AWG)
  • Material: Thermoplastic (PBT, UL94V-0)
  • Insulation Class: A
  • Insulation Resistance: ≥10 MΩ (500 V DC)
  • Operating Temperature: -10°C to +70°C
  • Life Expectancy: 70,000 hours at 40°C
  • Additional Features: Auto restart after lock
  • Certifications: CE, TÜV, RoHS

📌 Description

This compact 60 mm axial fan with Vapo-Bearing™ ensures quiet and reliable operation. Ideal for cooling electronics, servers, automation systems, and other industrial applications

Specification
