FAN 12VDC 60x60x10mm, 24m3/h, 25dBA
Code IVT2061- Manufacturer SUNON
- ID code MF60101V21000UA99
- Weight 31.00g
E-shop price: 6,50 €
| Amount: | 3+ | 4+ |
| Price: | 6,18 | 5,92 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item available (2) | |
| Shop in Vilnius | Item available (2) | |
| Shop in Kaunas | Item available (4) | |
Description
🌬️ Sunon MF60101V2-1000U-A99 – DC Axial Fan
Manufacturer: SUNON
Model: MF60101V2-1000U-A99
Series: MagLev® MF
🔧 Technical Specifications
- Voltage: 12 V DC (operating range: 4.5–13.8 V)
- Current: 75 mA
- Power Consumption: 0.9 W
- Speed: 3500 RPM
- Airflow: 24.17 m³/h (14.3 CFM)
- Static Pressure: 2.54 mm H₂O
- Noise Level: 25 dBA
- Bearing Type: Vapo-Bearing™
- Dimensions: 60 × 60 × 10 mm
- Weight: 23 g
- Lead Length: 290 mm (2 wires, 26 AWG)
- Material: Thermoplastic (PBT, UL94V-0)
- Insulation Class: A
- Insulation Resistance: ≥10 MΩ (500 V DC)
- Operating Temperature: -10°C to +70°C
- Life Expectancy: 70,000 hours at 40°C
- Additional Features: Auto restart after lock
- Certifications: CE, TÜV, RoHS
📌 Description
This compact 60 mm axial fan with Vapo-Bearing™ ensures quiet and reliable operation. Ideal for cooling electronics, servers, automation systems, and other industrial applications
