MT-W-17S-11-9240-M Timer; Range: 0,1s÷99h59min59,9s; SPDT; 12÷240VAC; 12÷240VDC; IP20

• Number of pins — 6
• Supply voltage AC — 12V AC…240V AC
• Operating temperature — -20°C…50°C
• Supply voltage DC — 12V DC…240V DC
• Number of operation modes — 25
• —
• Counter operation modes — ON and OFF delay
• Counter operation modes — cyclical operation with two independent times T1 and T2, pause first
• Kind of output — SPDT
• Mounting — for DIN rail mounting
• Counting range — 0,1s...99h59min59,9s
• Output 1 electrical parameters — 250V AC / 10A
• —
• —
• Counter operation modes — delayed switching off
• Type of module — timer
• IP rating — IP20
• —
• Type of automation module — timer
• Kind of display used — LED
• —
• Display parameters — 7-segment x2
• Counter operation modes — cyclical operation with two independent times T1 and T2, pulse first
• Counter operation modes — delayed switching on
• —
• Manufacturer — RELPOL
• Output 1 electrical parameters — 24V DC / 10A
• Electrical connection — screw terminals
• Counter operation modes — with the control contact S
