RELAY 5V 6A/250VAC SPDT FINDER, 34.51.7.005.0010
Code RLF3405- Manufacturer FINDER
- ID code 34.51.7.005.0010
- Weight 6.00g
E-shop price: 7,90 €
| Amount: | 4+ | 8+ |
| Price: | 7,03 | 5,44 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item available (1) | |
| Shop in Vilnius | Item is not available (0) | |
| Shop in Kaunas | Item is not available (0) | |
Item description
Contacts configuration SPDT
Rated coil voltage 5V DC
AC contacts rating
(at resistance load) 6 A / 250 VAC
DC contacts rating
(at resistance load) 6 A / 30 VDC
Contact current max. 10A
Switched voltage max 250V AC, max 220V DC
Relay variant interface
Mounting PCB, socket
Coil resistance 130?
Coil voltage min. 3.5V DC
Coil voltage max. 7.5V DC
Body dimensions 25 x 5 x 15mm
Coil power consumption 170mW
Mechanical durability 1000000cycles
Operating temperature -40...85°C
Relay series 34.51
Contact material AgNi
Terminal pitch 5mm
Coil current 38.4mA
Associated items 93.01.7.024, 93.01.7.060, 93.11, 93.51.3.125, 93.51.3.240
