Thermal relay - Thermal protection 10A 150°C disconnect / 135°C connect
Code RLTL15L- Weight 10.00g
E-shop price: 1,95 €
| Amount: | 3+ | 6+ |
| Price: | 1,68 | 0,69 |
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item is not available (0) | |
| Shop in Vilnius | Item available (2) | |
| Shop in Kaunas | Item available (2) | |
Description
A bimetallic thermostat is designed to switch an electrical circuit at the appropriate temperature. The thermostat contacts are disconnected when the working temperature is reached. When the temperature drops, the contacts are reconnected.
Voltage limit : 250 VAC
Permissible current : up to 10 A
Terminals : 6,3 mm
Contact disconnects : at 100 ± 5 °C
Contact reconnects : at 80 ± 5 °C
Contact : NC (normally connected)
