SDS1052 Oscilloscope: digital; Ch: 2; 50MHz; 500Msps; 10kpts; LCD 7"; SDS

• Supply voltage — 100V…240V
• Supply voltage AC — 100V AC…240V AC
• Power consumption — 15W
• Supply voltage DC — 100V DC…240V DC
• Measurement memory — 16
• Measuring instrument features — X-Y operation mode
• Kind of connector — USB
• Standard equipment — mains cable
• —
• Standard equipment — oscilloscope probe (1 per channel)
• —
• Connection — USB
• Connectors for the country — Europe
• Band — 50MHz
• —
• —
• —
• Standard equipment — user's manual
• Measuring instrument features — mathematical functions: addition, subtraction, multiplification, division and signal phase reversing
• —
• Measuring instrument features — AUTOSET function for setting display parameters (time base, gain)
• Manufacturer — OWON
• —
• Kind of display used — LCD 7"
• Sampling — 500Msps
• —
• Measuring instrument features — compact design
• Standard equipment — USB cable
• Software — included
• Display resolution — 800x480
• —
• —
• Interface — USB
• —
• —
• —
• Input impedance — 1MΩ/20pF
• —
• —
• Body dimensions — 301x152x70mm
• —
• Measuring instrument features — FFT analysis
• Number of channels — 2
• —
• —
