BREVE TUFVASSONS TEZ 15.0/D 16015-9969 encapsulated PCB transformer, 230 V / 15 V, 15 VA, 1 A

BREVE TUFVASSONS TEZ 15.0/D 16015-9969 encapsulated PCB transformer, 230 V / 15 V, 15 VA, 1 A

The BREVE TUFVASSONS TEZ 15.0/D 16015-9969 is a single-phase resin-encapsulated mains transformer designed for direct mounting on printed circuit boards in electronic power-supply circuits. It converts a 230 V AC primary supply to a 15 V AC secondary output and provides a rated secondary current of up to 1 A at 15 VA. Its compact resin-encapsulated construction improves resistance to mechanical and climatic factors.

Key parameters:
230 V AC → 15 V AC • 15 VA • 1 A • PCB mounting • Ta 60 °C • IP00

Key features and benefits

• 15 VA rated power – suitable for electronic power circuits requiring up to 1 A at 15 V AC.
• 230 V AC primary winding – intended for operation from a 230 V AC mains supply.
• 15 V AC / 1 A secondary – provides one 15 V AC secondary output.
• PCB mounting – solder pins allow the transformer to be integrated directly into a printed circuit board.
• Resin-encapsulated construction – according to the manufacturer, resin encapsulation improves mechanical integrity and resistance to climatic factors.
• Class B insulation system – thermal insulation class B corresponds to a 130 °C class.
• Up to 60 °C ambient temperature – the TEZ 15.0/D version is specified for an ambient temperature of up to 60 °C.
• Compact dimensions – approximately 44 × 52 × 41.5 mm for convenient integration into PCB-based equipment.
• EN 61558 series compliance – the manufacturer specifies EN 61558-2-1, EN 61558-2-4 and EN 61558-2-6 for the TEZ series.
• ENEC certification range – BREVE states ENEC certification for TEZ transformers, and this model's electrical ratings fall within the published certification range.

Applications

The transformer is intended for integration into printed circuit boards and power-supply sections of electronic equipment. Typical applications include control electronics, automation circuits, low-power power-supply assemblies and other devices requiring 15 V AC at up to 1 A from a 230 V AC mains input.

It is an embedded electrical component rather than a complete stand-alone power supply.

Compatibility and limitations

• Intended for 230 V AC, 50/60 Hz primary circuits.
• The secondary output is 15 V AC, not 15 V DC.
• Applications requiring DC need an external rectifier, filtering and, where necessary, voltage regulation.
• Designed for direct PCB mounting; it is not a DIN-rail or stand-alone enclosed transformer.
• The IP00 rating means it must be installed inside a suitably protected final device rather than operated as an exposed mains component.
• BREVE specifies short-circuit resistance only for TEZ models rated from 0.5 to 3 VA; no such specification is stated for the 15 VA TEZ 15.0/D.

Technical specifications

Parameter	Value
Manufacturer	BREVE TUFVASSONS
Series	TEZ
Model	TEZ 15.0/D 230/15V
Manufacturer part number	16015-9969
Product type	Single-phase resin-encapsulated PCB transformer
Rated power	15 VA
Primary voltage	230 V AC
Frequency	50/60 Hz
Secondary voltage	15 V AC
Number of secondary windings	1
Rated secondary current	1 A
Number of phases	1
Mounting	PCB, solder pins
Primary winding terminals	1–6
Secondary winding terminals	8–11
Pin pitch within row	5 mm
PRI-to-SEC row spacing	27.5 mm
Pin layout width	25 mm
Pin diameter according to drawing	Ø0.8 mm
Recommended PCB hole diameter	1.2 mm
Protection rating	IP00
Insulation thermal class	B (130 °C)
Maximum ambient temperature Ta	60 °C
Construction	Resin encapsulated
Core type	EI type
Housing	PA
Dimensions A × B × C	44 × 52 × 41.5 mm
Dimensional tolerance	±0.4 mm
Weight	approx. 0.35 kg
Standards	EN 61558-2-1, EN 61558-2-4, EN 61558-2-6
Certification	ENEC certification specified by the manufacturer for the TEZ range

Construction and mounting

The transformer uses an EI-type magnetic core and is resin encapsulated in a PA housing. This creates a compact module intended for direct mounting on a printed circuit board.

For the TEZ 15.0/D pin configuration, the primary winding is connected to terminals 1 and 6, while the single secondary winding uses terminals 8 and 11. BREVE recommends approximately 1.2 mm PCB holes for the pins.

Important safety and operating notes

The primary circuit is connected to hazardous 230 V AC mains voltage. PCB layout and final equipment design must therefore comply with applicable electrical safety, insulation-clearance and protection-against-contact requirements.

The IP00 construction does not provide stand-alone protection against direct contact or environmental exposure, so the transformer must be properly enclosed in the final equipment.

Do not exceed the 15 VA rated power, 1 A rated secondary current or the specified maximum ambient temperature.
